Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer, Tool Only Technical Specifications:

• Max Cap. (concrete drilling): 1”
• Optimum Range (concrete): 3/16” – 1/2”
• Impact Energy (Joules): 2.4 J
• Impact Energy (ft.lbs.): 1.7
• Vibration (m/s²): 13.5
• No Load Speed (var. speed): 0 – 950 RPM
• Blows Per Min. (var. speed): 0 – 4,700 BPM
• Battery: 18V LXT® Lithium-Ion
• Overall Length: 12-7/8”
• Net Weight (with battery): 7.2 lbs.
• Bit Type: Accepts SDS-PLUS
• Power Type: Cordless
• Bind-Up Control: No
• Form Factor (LXT): 18V LXT®
• Motor Type: Brushless
• Shipping Weight: 7.1 lbs.
• UPC Code: 088381-654333

Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer, Tool Only Description

The Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer, Tool Only, is a versatile and powerful concrete drilling solution designed for maximum efficiency. Powered by an efficient Makita BL™ Brushless Motor, this rotary hammer delivers up to 50% longer run time, increased power and speed, and extended tool life.

With a no-load speed of 0-950 RPM, an impressive BPM of 4,700, and 1.7 ft.lbs of impact energy, the Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer ensures fast and effective drilling performance. It offers three operating modes: rotation only, hammering with rotation, and hammering only, providing versatility for various applications. The large 2-finger trigger enhances convenience and comfort during use, while the depth adjustment guide enables precise and accurate drilling depths.

For improved dust extraction without the hassle of cords, the Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer is compatible with the optional HEPA Dust Extraction Vacuum Attachment (model DX01, sold separately), allowing for cleaner and safer work environments. This rotary hammer is part of Makita’s expanding 18V Lithium-Ion system, the world’s largest cordless tool system powered by 18V Lithium-Ion slide-style batteries. Makita’s 18V Lithium-Ion batteries boast the fastest charge times in their categories, maximizing work time and minimizing downtime.

Makita’s Star Protection Computer Controls™ ensure enhanced tool performance and extended battery life. This innovative communication technology enables real-time data exchange between the tool and battery, monitoring conditions during use to protect against overloading, over-discharging, and overheating. Additionally, the Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer can be powered by Makita 18V LXT® and Compact Lithium-Ion batteries with the star symbol, providing increased versatility and compatibility.

The Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer features an efficient BL™ Brushless motor that optimizes battery energy usage, resulting in up to 50% longer run time per charge. By eliminating carbon brushes, the BL™ Motor runs cooler and more efficiently, contributing to its longer lifespan. With a compact and ergonomic design measuring only 12-7/8” in length and weighing just 7.2 lbs. (battery not included), this rotary hammer minimizes operator fatigue, allowing for extended periods of use.

The variable speed trigger enables users to match the speed to the application, offering greater versatility and control. With 40 different chisel positions, the Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer ensures optimal alignment with the application for improved comfort and precision. The torque limiting clutch automatically disengages gears if the bit binds, preventing gear damage and ensuring long-term durability.

Thanks to the sequential impact timing feature, the Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer provides timed hammering during rotation, minimizing overlapping bit impacts and resulting in up to 50% faster drilling. The job site-tested shock-absorbent handle protects the battery housing, adding an extra layer of durability to the tool.

For optimal battery life, the Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer is compatible with Makita’s Rapid Optimum Charger, which communicates with the battery’s built-in chip to actively control current, voltage, and temperature during the charging process. The charger’s built-in fan cools the battery for faster and more efficient charging. Makita’s technology guarantees category-leading charge times, ensuring that the battery spends more time working and less time sitting on the charger.

The Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer is compatible with Makita 18V Lithium-Ion batteries featuring the Star symbol (battery sold separately). It is backed by a 3-year limited warranty, providing peace of mind and assurance of its quality and performance. Remember to use only genuine Makita batteries and chargers for optimal compatibility and performance.

Makita XRH01Z 18V LXT Lithium-Ion Brushless Cordless 1” SDS-PLUS Rotary Hammer, Tool Only includes:

• (1) Side Handle (158057-6)
• (1) Depth Gauge (324219-0)
