M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets

Price: $695.10

Part Number: M2X200RG4

M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets. Actuation/Throttle Type/Switch Location: Handle Actuation/Throttle Type/Switch Type: Safety Lever Air Consumption @ Free Speed (cfm): 20 cfm

M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets Description

The M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets meets all your industrial, heavy machinery, construction and metal fabrication needs. These Die grinders contain an internal contamination-free air controller that maintains the tools speed to maximize material removal – so you can trust it to work through your most important jobs.

With a powerful, lube-free 1 HP 20,000RPM motor, you can remove materials quickly and with ease. Suited for heavier-duty grinding, cutting, cleaning, and polishing applications. The speed-governed motor on this grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity. Built to last, these grinders have an aluminum-core housing with a composite sleeve and can withstand harsh environments and repeated drops. Low-profile throttle lever and ergonomic handle designed for enhanced operator comfort, to reduce fatigue, and to improve productivity while using this Die grinder. A quick-change spindle-lock eliminates the need for additional tools. Easy disassembly for motor access. Back cap and muffler with easy rear access for cleaning. The M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets provides reliable results across demanding tasks.

Product Applications: Heavier-duty grinding, cutting, cleaning, and polishing applications.

The M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets is backed by a 1-year warranty for peace of mind.

Technical Specifications

Additional information

Part Number

M2X200RG4

Actuation/Throttle/Switch

Safety Lever

Air Con. @ Free Speed (cfm)

20 cfm

Air Con. @ Free Spd (l/min)

566 l/min

Air Consumption @ Load (cfm)

40 cfm

Air Cons. @ Load (l/min)

1133 l/min

Air Inlet

3/8'' NPT

Air Pressure (psi)

90 PSI

Arbor/Collet

1/4'' and 6mm

Bearing Type

Ball Bearing, Needle Bearing

Color

Grey

Configuration/Handle Type

Straight

Duty Rating

Industrial Duty

Exhaust Location

Rear

Grinder Type

Die Grinder

Handle Material

Composite

Height Over Spindle

2.15'' / 55mm

Housing Material

Aluminum Core with Composite Sleeve

Lock Mechanism

Lever Lock in Off Position

Max Free Speed (rpm)

20000RPM

Max Pressure

6.2 bar

Min. Hose Size

3/8''

Power Source

Air Powered

Product Length

13.08'' / 332mm

Product Weight

2.68lbs / 1.22kg

Rated Power

1hp / 0.75kW

Sound Pressure/Power Db(A)

84.9 / 95.9

Speed Setting

Variable Speed

UPC

663024008690

Vibration Level (M/S2)

1.9m/s2

Warranty

1-year

Wheel Type

Burr

M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets Description

The M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets meets all your industrial, heavy machinery, construction and metal fabrication needs. These Die grinders contain an internal contamination-free air controller that maintains the tools speed to maximize material removal – so you can trust it to work through your most important jobs.

With a powerful, lube-free 1 HP 20,000RPM motor, you can remove materials quickly and with ease. Suited for heavier-duty grinding, cutting, cleaning, and polishing applications. The speed-governed motor on this grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity. Built to last, these grinders have an aluminum-core housing with a composite sleeve and can withstand harsh environments and repeated drops. Low-profile throttle lever and ergonomic handle designed for enhanced operator comfort, to reduce fatigue, and to improve productivity while using this Die grinder. A quick-change spindle-lock eliminates the need for additional tools. Easy disassembly for motor access. Back cap and muffler with easy rear access for cleaning. The M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets provides reliable results across demanding tasks.

Product Applications: Heavier-duty grinding, cutting, cleaning, and polishing applications.

The M2X200RG4 Ingersoll Rand 20000RPM Rear Exhaust Extended Inline Air Die Grinder, 1/4” and 6mm Collets is backed by a 1-year warranty for peace of mind.

Additional information

Part Number

M2X200RG4

Actuation/Throttle/Switch

Safety Lever

Air Con. @ Free Speed (cfm)

20 cfm

Air Con. @ Free Spd (l/min)

566 l/min

Air Consumption @ Load (cfm)

40 cfm

Air Cons. @ Load (l/min)

1133 l/min

Air Inlet

3/8'' NPT

Air Pressure (psi)

90 PSI

Arbor/Collet

1/4'' and 6mm

Bearing Type

Ball Bearing, Needle Bearing

Color

Grey

Configuration/Handle Type

Straight

Duty Rating

Industrial Duty

Exhaust Location

Rear

Grinder Type

Die Grinder

Handle Material

Composite

Height Over Spindle

2.15'' / 55mm

Housing Material

Aluminum Core with Composite Sleeve

Lock Mechanism

Lever Lock in Off Position

Max Free Speed (rpm)

20000RPM

Max Pressure

6.2 bar

Min. Hose Size

3/8''

Power Source

Air Powered

Product Length

13.08'' / 332mm

Product Weight

2.68lbs / 1.22kg

Rated Power

1hp / 0.75kW

Sound Pressure/Power Db(A)

84.9 / 95.9

Speed Setting

Variable Speed

UPC

663024008690

Vibration Level (M/S2)

1.9m/s2

Warranty

1-year

Wheel Type

Burr
