Jacobs drill sleeves, morse taper, Archer series 600. Model Number: 642 Morse Taper Number Outside: 4 Morse Taper Number Inside: 2 Overall Length: 4.88”
Jacobs Drill Sleeves, Morse Taper, Archer Series 600 Description: Adapt smaller morse taper shank tools to larger machine spindles. Oil toughened and externally precision ground with hardened tang.
Technical Specifications: Model Number: 642 Morse Taper Number Outside: 4 Morse Taper Number Inside: 2 Overall Length: 4.88” UPC: 95456304260
| Model Number | 642 |
|---|---|
| Morse Taper Number Outside | 4 |
| Morse Taper Number Inside | 2 |
| Overall Length | 4.88'' |
| Closed Length | 3.54'' |
| Open Length | 3.23'' |
| Sleeve Diameter | 1.89'' |
| UPC | 95456314108 |
Jacobs Drill Sleeves, Morse Taper, Archer Series 600 Description: Adapt smaller morse taper shank tools to larger machine spindles. Oil toughened and externally precision ground with hardened tang.
Technical Specifications: Model Number: 642 Morse Taper Number Outside: 4 Morse Taper Number Inside: 2 Overall Length: 4.88” UPC: 95456304260
| Model Number | 642 |
|---|---|
| Morse Taper Number Outside | 4 |
| Morse Taper Number Inside | 2 |
| Overall Length | 4.88'' |
| Closed Length | 3.54'' |
| Open Length | 3.23'' |
| Sleeve Diameter | 1.89'' |
| UPC | 95456314108 |
