2950B7 Ingersoll Rand 3000 ft-lbs Heavy Duty D-Handle Inside Trigger Air Impact Wrench, 1-1/2” Square Drive. Actuation/Throttle Type/Switch Type: Inside Trigger Air Inlet: 1/2” NPT Air Pressure (PSI): 90 PSI Anvil Length: Standard
The 2950B7 Ingersoll Rand 3000 ft-lbs Heavy Duty D-Handle Inside Trigger Air Impact Wrench, 1-1/2” Square Drive features a finely tuned motor and excellent power regulation, and is ready to assist you on even the toughest of jobs.
The 2950 Series features a steel hammer case and metal housing, tough enough to last through any drops or harsh weather conditions. This tool’s twin hammer impact mechanism provides an even blow that delivers every time. Great for outdoor environments, this wrench contains a bronze end-plate that increases durability and is corrosion resistant.
Engineered to withstand the harshest working conditions in oilfields, mines, and shipyards.
The 2950B7 Ingersoll Rand 3000 ft-lbs Heavy Duty D-Handle Inside Trigger Air Impact Wrench, 1-1/2” Square Drive is backed by a 1-year warranty for peace of mind.
| Part Number | 2950B7 |
|---|---|
| Actuation/Throttle/Switch | Inside Trigger |
| Air Inlet | 1/2'' NPT |
| Air Pressure (psi) | 90 PSI |
| Anvil Length | Standard |
| Average Air Cons. (cfm) | 70 cfm |
| Average Air Cons. (l/min) | 1982 l/min |
| Blows per Min | 650 BPM |
| Color | Grey |
| Configuration/Handle Type | D-Handle |
| Drive Size | 1-1/2'' |
| Drive Type | Square |
| Duty Rating | Heavy Duty |
| End Plates | Bronze |
| Exhaust Location | Bottom |
| Free Spd Sound Press./Pwr | 94.9 / 105.9 |
| Hammer Case | Steel |
| Handle Material | Composite |
| Housing Material | Aluminum |
| Impact Mechanism | Twin Hammer |
| Max Bolt Diameter | 1.5'' |
| Max Free Speed (rpm) | 3750RPM |
| Max Pressure | 6.2 bar |
| Max Torque | 3000 ft-lbs / 35996 in-lbs / 4067 Nm |
| Min. Hose Size | 3/4'' |
| Motor | Reverse Bias |
| Number of Power Settings | Continuous |
| Power Source | Air Powered |
| Product Length | 14.5'' / 368mm |
| Product Weight | 32.6lbs / 14.79kg |
| Rec. Forward Torque Range | 2500 ft-lbs / 30004 in-lbs / 3390 Nm |
| Recommended Reverse Torque | 1601-2500 ft-lbs / 2170-3390 Nm |
| Retainer Type | Thru-hole |
| Side to Center Distance (in) | 2.5'' / 64mm |
| Speed Setting | Variable Speed |
| Standards/Certifications | CE |
| Tool Type | Full-size |
| UPC | 663023011875 |
| Vanes | 6 |
| Vibration Level (M/S2) | 18.1m/s2 |
| Warranty | 1-year |
