259 Ingersoll Rand 3/4” Square Drive Pistol Grip Air Impact Wrench. Actuation/Throttle Type/Switch Type: Trigger Air Consumption @ Load (cfm): 30 cfm Air Consumption @ Load (l/min): 850 l/min Air Inlet: 3/8” NPT Air Pressure (PSI): 90 PSI
The 259 Ingersoll Rand 3/4” Square Drive Pistol Grip Air Impact Wrench is great for jobs in vehicle repair and heavy truck markets. Backed by Ingersoll Rands strong reputation of developing industry-leading tools, the 259 Series can be counted on for durable and consistent power at a great value.
With the 259 Series aluminum hammer case and powerful vane motor, this impact wrench offers a great power-to-weight ratio. These parts will stand the test of time. The rocking dog impact mechanism is easy to maintain, and delivers a powerful burst with low air needs. The aluminum hammer case and pistol grip make the 259 Ingersoll Rand 3/4” Square Drive Pistol Grip Air Impact Wrench easy to hold, while the power regulator offers deeper control during use. Patent-pending soft-mount system reduces vibration for extended motor and switch life. Handle-vented exhaust directs air away from the operator. Silenced exhaust reduces tool noise while using this pneumatic impact wrench. Feather-touch trigger provides maximum speed control. Ergonomically designed small-handle grip helps reduce operator fatigue during extended use of this pneumatic air wrench. Optimized for the vehicle repair industry and heavy trucks. Non-biased motor delivers 1,050 ft-lbs of maximum torque in both forward and reverse.
The 259 Ingersoll Rand 3/4” Square Drive Pistol Grip Air Impact Wrench is backed by a 1-year warranty for peace of mind.
| Part Number | 259 |
|---|---|
| Actuation/Throttle/Switch | Trigger |
| Air Consumption @ Load (cfm) | 30 cfm |
| Air Cons. @ Load (l/min) | 850 l/min |
| Air Inlet | 3/8'' NPT |
| Air Pressure (psi) | 90 PSI |
| Anvil Length | Standard |
| Average Air Cons. (cfm) | 8 cfm |
| Average Air Cons. (l/min) | 227 l/min |
| Blows per Min | 1000 BPM |
| Color | Silver |
| Configuration/Handle Type | Pistol Grip |
| Drive Size | 3/4'' |
| Drive Type | Square |
| Duty Rating | General Duty |
| End Plates | Steel |
| Exhaust Location | Bottom |
| Free Spd Sound Press./Pwr | 96.5 / 107.5 |
| Hammer Case | Aluminum |
| Handle Material | Aluminum |
| Housing Material | Aluminum |
| Impact Mechanism | Rocking Dog |
| Impact Sound Prs/Pwr Db(A) | 91.6 / 102.6 |
| Max Bolt Diameter | 7/8'' |
| Max Free Speed (rpm) | 6000RPM |
| Max Pressure | 6.2 bar |
| Max Torque | 1050 ft-lbs / 12603 in-lbs / 1424 Nm |
| Min. Hose Size | 3/8'' |
| Motor | Non-Biased |
| Number of Power Settings | 2 |
| Power Source | Air Powered |
| Nut-busting Torque/Weight | 119.3 ft-lbs/lbs |
| Product Height | 8.5'' / 216mm |
| Product Length | 8.6'' / 218mm |
| Product Weight | 8.8lbs / 3.99kg |
| Product Width | 3.2'' / 81mm |
| Rec. Forward Torque Range | 201-800 ft-lbs / 2407-9603 in-lbs / 272-1085 Nm |
| Retainer Type | Friction Ring |
| Side to Center Distance (in) | 1.6'' / 41mm |
| Standards/Certifications | Cagi B186, Iso 11148-6, Iso 15744, Iso 28927-2 |
| Tool Type | Full-size |
| UPC | 663023076539 |
| Vanes | 6 |
| Vibration Level (M/S2) | 6.4m/s2 |
| Warranty | 1-year |
