2217-20 Milwaukee True RMS Multimeter Tool Warranty: 5 Years Battery Type: Alkaline (AA) Display Type: White on Black LCD Length: 6-1/2” Switch Type: Dial TRMS: Yes Current AC DC: 10.00A Voltage AC DC: 600V
Milwaukee 2155-AC RADIUS LED 70w Temporary Site Light The Milwaukee 2217-20 True RMS Multimeter is a heavy duty meter for professional residential, commercial and industrial applications. The perfect tool for professional electricians, the 2217-20 offers functionality users expect with features that make doing the job easier. The Milwaukee 2217-20 True RMS Multimeter features a large white on black display for clearer readings, a slide rail system to add proprietary accessories and rugged over-molding for increased durability and grip. The meter is rated to CATIII 600V and meets UL safety specifications required by electrical users. This meter is covered by Milwaukee’s 5-Year Warranty.
Milwaukee 2217-20 True RMS Multimeter Includes
| Part Number | 2217-20 |
|---|---|
| Tool Warranty | 5 Years |
| Battery type | Alkaline (AA) |
| Display Type | White on Black LCD |
| Length | 6-1/2'' |
| Switch Type | Dial |
| TRMS | Yes |
| Current AC DC | 10.00A |
| Voltage AC DC | 600V |
| Frequency | 10 Hz – 50.00 kHz |
| Resistance | 40M? |
| Continuity | Audible |
| Capacitance | 000?F, 1 |
| Contact Temperature | -40? F to 752? F (-40? C to 400? C) |
| Safety Category Rating | CAT III 600V |
| Lo Z | Yes |
| Backlight | Yes |
| HOLD MIN MAX | Yes |
| Bargraph | Yes |
| Rugged Overmolding | Yes |
| Accessory Attachment | Magnetic Meter Holder |
| Calibration Needed | Yes – Recommend calibration service once every year |
| UPC | 045242173471 |
